High Performance Door Frame Metal Detector With 6 Zones And High Sensitivity

large.img.alt
small.img.alt small.img.alt small.img.alt small.img.alt

Large Image :  High Performance Door Frame Metal Detector With 6 Zones And High Sensitivity Get Best Price

Product Details:
Place of Origin: China
Brand Name: UOUOU
Certification: CE, FCC, ROHS,ISO 9001:2008
Model Number: VO-2000
Payment & Shipping Terms:
Minimum Order Quantity: 1
Packaging Details: 1 pcs/ 2carton
Delivery Time: 1-2days after receive payments
Payment Terms: T/T ,Western Union
Supply Ability: 60000pcs/month
Detailed Product Description
High Light:

door frame metal detectors

,

walkthrough metal detectors



High Performance Door Frame Metal Detector With 6 Zones And High Sensitivity





Competitive Advantage:

High cost performance

6 zones

DSP and Microprocessor

FIFA World Cup South Africa Designated Products

Super high sensitivity



Features:

1.Consists of three parts: left-right detecting gate, mainframe and fix ware at the gate

2.There are 6 detecting areas spreading evenly over the left-right detecting gate board from its top to bottom, with built-in super shining LED indicating lights (it is called a 6 positions aide lights display detecting)

3.On the sides of left-right detecting gate board, there are aluminum alloy strips for protection, with built-in super shining LED indicating lights, it can exactly indicate the exact position of detected item

4.The control circuit, collecting circuit and calculation circuit are highly integrated, which are especially stable in performance, strong in anti-interference, exact in detecting and free from mistakes in reporting

5.Has the function of password protection

6.Has the function of recover systematic parameters by one-key

7.Can display detecting in sole region or display the detecting of multi regions at the same time (for instance, if there are metals in #3 and #5 regions at the same time, the LED indicating lights will turn on in both regions)

8.Has the function of 3-grade audio tones adjustment, adapting to different usage environments

9.Eight work frequency spots are set up in an array, standard distance to assemble the gate is 50cm

10.Information will be marked down on the front panel such as number of persons passed-by, times of alarm, strength of interfering signals and more

11.Sole detecting area can adjust its sensitivity privately, without coordination to adjust the overall sensitivity, it can be adjusted in 100 degrees within its scope, it can meet the customer's demand to reject the item such as belt buckle, gold or silver jewelry and more

12.No harm to cardiac pacemaker in human body, hearing aid, pregnant woman and CD compact disc and more

Applications:

Airport, Customs, Electronic Factory , Gymnasium, Court of Justice ,Adjudication Division , Prison , bull session VIP place , Nightclub, Bar and  so on

Specifications:

Product passage dimensions

2000mm*700mm*600mm

Product external dimensions

2230mm*830mm*600mm

Working Voltage

AC: 110V-220V

Working power

30W

Working temperature

-20℃~55℃

Gross weight:

62 kg( doorframe )

13.5kg ( mainframe)

High Performance Door Frame Metal Detector With 6 Zones And High Sensitivity
