Portable X Ray Security Scanner Compact with 100kV - 160kV Anode Volta

Portable X Ray Security Scanner Compact with 100kV - 160kV Anode Volta

Competitive Advantage:

Network interface : Could be connect local area network and support multi terminal check baggage at same times

Versatile Screening System

Compact Design

Portable

Cost Effective

Designed for rapid relocation and can be wheeled through narrow doorways, making it an excellent system for schools, hotels, convention centers and event-based security environments.

Feature:

1.Alarm by sounds and light: alarm by sounds and light when conform to condition

2.Network interface could be connect local area network and support multi-terminal check baggage at same times

3.Safety ray: transmit ray under automatic control, avoids the miss

4.Simple operation by mouse: without keyboard and work table, control by mouse, save space

5.Turn off by a key control: turn off the machine only need one step, revolves the key

6.The equipment automatic security close-down, does not need complex many steps, is simpler

7.Eagle-eye: could be expediently observing enlargement area

8.Estimate malfunction by self: automatic estimate malfunction and prompt message, helpful for the maintenance

9.With Threat Image Projection (TIP): which can record the dangerous items’ information ,and when detect the dangerous item, it will have the voice alarm.

X-ray generator:

Orientation: vertically upward

Tube current: 0.4 to 1.2mA (adjustable)

Anode voltage: 100 to 160kV (adjustable)

Angle: 80°

Generator cooling/working periods: sealed oil bath with forced air/100

Operating environment:

Storage temperature: -20 to 60°C

Operating temperature: 0 to 45°C

Relative humidity: 20 to 95% non-condensing

System power: 220V AC (±10%) 50 ± 3Hz

Power wastage: 1.0kW (maximum)

Noise: <65dB

Packing: 1pc/carton, 3.5CBM

Carton size: 205 x 95 x 135cm

Carton size (with plank/shelf): 125 x 75 x 85cm

Weight/carton: 750 kg

Applications:

schools, hotels, convention centers and event-based security environments

Specifications:
